PRODUCT / USB PRODUCY / RCU-4903P-1C

RCU-4903P-1C

USB 3.0 Type-C to 3A HUB + Giga Ethernet Adapter

■ Support USB 3.0, 2.0 and 1.1 Spec
■ Support parallel detection and automatic polarity correction
■ Support crossover detection and auto-correction
■ Support advanced link down power saving during Ethernet cable is unplugged
■ Support auto detach power saving, soft-disconnected from USB host when
Ethernet cable is unplugged
■ Support Wake on LAN (Suspend mode)
■ Support Super Speed (SS) transfer rates 5Gbps

Overview

USB Type C to 3A Hub and Ethernet adapter is an essential accessory for who want to utilize internet with higher mobility. Where wireless connectivity is not existent or overextended, , this adapter allows you to connect seamlessly and with confidence. With the speed and reliability of Gigabit Ethernet, even the largest downloads can be possible without fear of interruption. It features an USB-C plug cable and three USB-A (USB 3.1 Gen 1) ports with a Gigabit Ethernet port that complies with IEEE 802.3, 802.3u, 802.3ab.



Specifications

Standards
  • IEEE802.3 and IEEE802.3u
  • IEEE802.3X flow control for full duplex and back pressure flow control for half duplex
  • IEEE802.3az energy efficient Ethernet function
  • All USB power saving modes
I/O ports
  • Upstream ports: USB-C plug cable ×1
  • Downstream ports: USB-A ×3
  • RJ45 x 1, 10/100/1000Mbps Gigabit Ethernet
System Compatibility
  • Windows XP / Vista / Win 7 / Win 8 / Win 10 / Mac OS 10.x and Linux
LED Define
  • 1*Orange LED for speed (1000Mbps)
  • 1*Green LED for link (Data transferring: blinking)
USB Power
  • Bus-powered
Temperature
  • Operating : 0 to 40 °C (32 to 104 °F)
  • Storage : -20 to 60 °C (-4 to 140 °F)
Humidity
  • Operating : 10% to 90% , non-condensing
  • OStorage : 5% to 95% , non-condensing
Dimensions
  • 84(L) x50(W) x 14(H)mm
